G4779

7L/min Small vacuum pump mini air Pump With DC Brush/Brushless Motor

Model：GED12/24857
Air flow: 7L/min
Motor type: BLDC
Voltage: 12V/24V
Product description: GED12/24857 micro diaphragm pump is simply designed according to the principle of volume pump. It is to control the inlet and exit of the diaphragm, forming a power-driven rear drive mechanism to prom
INQUIRY EMAIL

Product Details

Product Name：Micro Vacuum Pump

Product Model：GED12/24857

Applications：

Medical usage：Gas transmission, applied to medical equipment

Factory usage：Vacuum adsorption, used in industrial equipment

Environmental usage：Gas sampling, used in environmental protection equipment

Beauty usage: Applied to beauty/physiotherapy equipment

Product features：

1.Maintenance-free ,Stable and adjustable speed 2.Accurate repeatability

3.Dry-running,self-priming 4.Long lifetime , well sealed

Datasheet：

Air parameter

Model

Air flow

Negative pressure

Positive pressure

Motor

Voltage

GED12/24857

7L/min

-0.085MPa

0.2MPa

DC,BLDC

12V/24V

Motor	Brush DC (DC)	Brushless DC (BLDC)
Temp	50℃	50℃
Noise level	<52dB	<50dB
Motor life	3000hrs	8000hrs
Work temp	0～40℃
Relative humidity	<80%
