JWP25

  • 0.95L/min High volume low pressure liquid pumps micro dc mini diaphragm vacuum pump
  • 0.95L/min High volume low pressure liquid pumps micro dc mini diaphragm vacuum pump
  • 0.95L/min High volume low pressure liquid pumps micro dc mini diaphragm vacuum pump
  • 0.95L/min High volume low pressure liquid pumps micro dc mini diaphragm vacuum pump
0.95L/min High volume low pressure liquid pumps micro dc mini diaphragm vacuum pump 0.95L/min High volume low pressure liquid pumps micro dc mini diaphragm vacuum pump 0.95L/min High volume low pressure liquid pumps micro dc mini diaphragm vacuum pump 0.95L/min High volume low pressure liquid pumps micro dc mini diaphragm vacuum pump

0.95L/min High volume low pressure liquid pumps micro dc mini diaphragm vacuum pump

  • Liquid flow:400mL/min
  • Air flow:0.95L/min
  • Vacuum:-0.015MPa
  • Voltage:12V
  • Product description: High volume low pressure liquid pumps micro dc mini diaphragm vacuum pump
  • INQUIRY   EMAIL

High volume low pressure liquid pumps micro dc mini diaphragm vacuum pump

■ Equipped with speed control signal port

Liquid flow: 400mL / min

Gas flow: 0.95L / min

Vacuum degree: -15kPa

■ Overall life: Quality version> 10000hrs (exhaust) 6000hrs (pump)

Voltage: 12V


Model

Air

Liquid

Air lifetime

Liquid lifetime

Voltage

Current

Flow

Vacuum

Voltage

Current

Flow

BLDC

mA

L/min

kPa

V DC

mA

L/min

hrs

hrs

JWP25

12

170

0.95

-15

12

250

0.4

10000

6000


Features:

1.Many control interface

All products are equipped with the following control interfaces as standard:

PWM: Input the PWM signal to change the medium flow rate by changing the motor speed.

FG: Output the speed feedback signal to know the running status of the pump, which is convenient for abnormal alarm or closed loop control.

START / STOP: Input the start-stop control signal to achieve continuous power-on

Stop control, easy to control pump operation through solid state circuit;

It is suitable for controlling frequent starting and stopping of the pump.

2.High reliability

Designed and selected for industrial applications, and carefully selected suppliers. Before leaving the factory, they run through the pre-run-in one by one to screen out the problem individuals.

3. Liquid and gas

It can be used for pumping liquids or vacuum pumps for pumping gas or gas-liquid mixed media.

4. Unrestricted installation attitude

The pump can be installed on an inclined surface, an upright surface or an inverted installation on the top surface, and it can work normally.

5 Self-protection function

All systems are equipped with overheat protection and overload protection as standard.

6. Maintenance-free

Full life without lubrication and downtime maintenance.

7. Low electromagnetic interference

There is no mechanical commutator structure, and no strong electromagnetic interference is generated from the reversing spark well of the brush motor.

8.No pollution transmission

It belongs to "oil-free pump" and does not contaminate the medium being transferred.

6.Dry rotation, self-priming, good corrosion resistance

Dry running is allowed without the need for "diversion". The pump cavity is made of reinforced nylon and EPDM rubber materials, and has good chemical stability.

7. Long life, continuous operation under heavy load.

Equipped with high-quality brushless motor; it can run continuously day and night under heavy load.
