1855-3915ml/min Peristaltic Pump Large Flow Chemical Water Food Dispense System

  • Model:353K
  • Motor:DC/STEP
  • Voltage:12V/24V
  • Flow:1855-3915ml/min
  • Product description: 1855-3915ml/min Peristaltic Pump Large Flow Chemical Water Food Dispense System
  • INQUIRY   EMAIL

Product Details

Product Name:Micro Peristaltic Pump

Product Model:353K

Applications:

Detergent equipment : such as washing machine, dishwasher

Analytical instrument: analytical testing instrument sample

Printing equipment: ink,solvant

conveying machinery: such as beverage machine, coffee machine, milk machine

Kitchen equipment  Laundry equipment  Car washing equipment  Analysis equipment

Product Features:

1.  Max Flow Rate up to 3915ml/min

2.  Standard tube is  73#,82#

3.  Easy to load the pump cover and tube

4.  Several types of motors for choose: DC motor,DC gear motor

5.  Crust Material:PC,PA66


Rated voltage

DC 24V, 2A

Power

≤48W

Operating environment

Temperature 0~60, relative humidity less than 85%

Net weight

1282g

Outlet pressure

≤0.17MPa

Noise

≤67dB (testing environment noise≤50dB. The horizontal distance between the test product and the noise meter is 1 meter.)

Function

Start/stop, cw/ccw rotation, up/down speed

Flow amount (ml/min,suction 0.8m,lift 0.4m)

Tube

Voltage/RPM

Silicone tube

Norprene A-60-F tube

Norprene chemical tube

73#

82#

73#

82#

73#

82#

135rpm

2075

3085

1905

2820

1855

2700

166rpm

2655

3915

2400

3555

2340

3390
